| 鋼 | 不銹鋼 | 鑄鐵 | 有色金屬 | 高溫合金 |
| ◎ | ◎ | ◎ |
| 產(chǎn)品編碼 ltem code | 刃徑 d1（h7） | 螺紋尺寸 M公制 | 柄徑 d2（h6） | 總長 I1 | 槽長 I2 | 最大切深 I3 | 柄長 I4 |
| D3020-CHA-D03000 | 3 | 6 | 107 | 65 | 60 | 36 | |
| D3020-CHA-D03175 | 3.175 | 1/8" | 6 | 134 | 92 | 86 | 36 |
| D3020-CHA-D03500 | 3.5 | 6 | 134 | 92 | 86 | 36 | |
| D3020-CHA-D03572 | 3.572 | 9/64" | 6 | 134 | 92 | 86 | 36 |
| D3020-CHA-D03969 | 3.969 | 5/32" | 6 | 134 | 92 | 86 | 36 |
| D3020-CHA-D04000 | 4 | 6 | 134 | 92 | 86 | 36 | |
| D3020-CHA-D04500 | 4.5 | 6 | 158 | 118 | 110 | 36 | |
| D3020-CHA-D04763 | 4.763 | 3/16" | 6 | 158 | 118 | 110 | 36 |
| D3020-CHA-D04800 | 4.8 | 6 | 158 | 118 | 110 | 36 | |
| D3020-CHA-D05000 | 5 | 6 | 158 | 118 | 110 | 36 | |
| D3020-CHA-D05500 | 5.5 | 6 | 170 | 132 | 123 | 36 | |
| D3020-CHA-D05556 | 5.556 | 7/32" | 6 | 182 | 144 | 135 | 36 |
| D3020-CHA-D05800 | 5.8 | 6 | 182 | 144 | 135 | 36 | |
| D3020-CHA-D06000 | 6 | 6 | 182 | 144 | 135 | 36 | |
| D3020-CHA-D06100 | 6.1 | 8 | 200 | 162 | 151 | 36 | |
| D3020-CHA-D06350 | 6.35 | 1/4" | 8 | 200 | 162 | 151 | 36 |
| D3020-CHA-D06500 | 6.5 | 8 | 200 | 162 | 151 | 36 | |
| D3020-CHA-D06800 | 6.8 | 8 | 200 | 162 | 151 | 36 | |
| D3020-CHA-D07000 | 7 | 8 | 200 | 162 | 151 | 36 | |
| D3020-CHA-D07144 | 7.144 | 9/32" | 8 | 222 | 184 | 172 | 36 |
| D3020-CHA-D07400 | 7.4 | 8 | 222 | 184 | 172 | 36 | |
| D3020-CHA-D07500 | 7.5 | 8 | 222 | 184 | 172 | 36 | |
| D3020-CHA-D07938 | 7.938 | 5/16" | 8 | 222 | 184 | 172 | 36 |
| D3020-CHA-D08000 | 8 | 8 | 222 | 184 | 172 | 36 | |
| D3020-CHA-D08300 | 8.3 | 10 | 240 | 198 | 184 | 40 | |
| D3020-CHA-D08500 | 8.5 | 10 | 240 | 198 | 184 | 40 | |
| D3020-CHA-D08731 | 8.731 | 11/32" | 10 | 240 | 198 | 184 | 40 |
| D3020-CHA-D09000 | 9 | 10 | 240 | 198 | 184 | 40 | |
| D3020-CHA-D09525 | 9.525 | 3/8" | 10 | 262 | 220 | 205 | 40 |
| D3020-CHA-D09800 | 9.8 | 10 | 262 | 220 | 205 | 40 | |
| D3020-CHA-010000 | 10 | 10 | 262 | 220 | 205 | 40 | |
| D3020-CHA-00200 | 10.2 | 12 | 289 | 242 | 225 | 45 | |
| D3020-CHA-00319 | 10.319 | 13/32" | 12 | 289 | 242 | 225 | 45 |
| D3020-CHA-01000 | 11 | 12 | 289 | 242 | 225 | 45 | |
| D3020-CHA-01113 | 11.113 | 7/16" | 12 | 311 | 264 | 246 | 45 |
| D3020-CHA-01500 | 11.5 | 12 | 311 | 264 | 246 | 45 | |
| D3020-CHA-01800 | 11.8 | 12 | 311 | 264 | 246 | 45 | |
| D3020-CHA-01906 | 11.906 | 15/32" | 12 | 311 | 264 | 246 | 45 |
| D3020-CHA-02000 | 12 | 12 | 311 | 264 | 246 | 45 |
